| Categories | Indoor Distribution Box |
|---|---|
| Brand Name: | QK |
| Model Number: | 20-30-15 |
| Certification: | RoHS, CE, UL,CCC,ISO9001 |
| Place of Origin: | China |
| MOQ: | 1 Piece |
| Price: | Negotiation |
| Payment Terms: | T/T,L/C,Western Union |
| Supply Ability: | 1000 Pieces/month |
| Delivery Time: | 5-8 work days |
| Packaging Details: | Regular export packing and can accept customized |
| Material: | Sheet Steel/Stainless Steel |
| Thickness: | 1.0/1.2/1.5mm |
| Delivery Date: | 5-8 Work days |
| Door: | Single Door |
| Ground wire: | Yes |
| Paint Finish: | Epoxy Polyester Coating |
Distribution boxes and distribution cabinets, distribution panels, distribution panels, etc., are centrally installed switchgear, meters and other equipment sets.
Commonly used distribution box has two kinds of wood and metal, because metal distribution box protection level is higher, so metal is still used more.
The use of distribution box: reasonable distribution of electrical energy to facilitate the operation of circuit opening and closing. It has a higher level of safety protection, which can visually display the conduction state of the circuit.
Construction
1. Body and door manufactured in 1.2/1.5mm sheet stell.
2. Mounting plate with folded edge In 2.0 mm sheet steel
3. Finished with thermosetting epoxy polyester powder coating. Body
and door textured finish.
4. Mounting plate in smooth finish.
5. Protection Degree IP 55/65 protection degree
Boxes are completed with:
1. Two zincpassivated rails to be fixed on the door.
2. Mounting plate.
3. Gland plate and gasket.
4. Package with hardware for earth connection and screws to mount
all Components.
Industrial 3 phase power distribution box
| Product name | Distribution box |
| Material | Sheet Steel |
| OEM | Offered |
| Package | 1 Piece Per Carton |
| Certification | CE,CCC,ROHS,TUS |
| Paint Finish | Epoxy Polyester Coating |
| Lock | Available On Request |
| Thckness | 1.2mm*1.5mm*1.5mm |
| Color | Ral7035 |
| Accessories | Wall Mount Brackets To Be Offered Seperately |
If you need specified product,please consult us.
| Standard | Overall Dimension | |||
| Height(mm) | Width(mm) | Depth(mm) | Thickness(mm) | |
| JXF302515 | 300 | 250 | 150 | 1.0/1.0/1.0 |
| JXF403015 | 400 | 300 | 150 | 1.0/1.2/1.2 |
| JXF504015 | 500 | 400 | 150 | 1.0/1.2/1.2 |
| JXF403020 | 400 | 300 | 200 | 1.0/1.2/1.2 |
| JXF504020 | 500 | 400 | 200 | 1.0/1.2/1.2 |
| JXF604020 | 600 | 400 | 200 | 1.0/1.2/1.2 |
| JXF605020 | 600 | 500 | 200 | 1.2/1.5/1.5 |
| JXF705020 | 700 | 500 | 200 | 1.2/1.5/1.5 |
| JXF806020 | 800 | 600 | 200 | 1.2/1.5/1.5 |
| JXF1008020 | 1000 | 800 | 200 | 1.5/1.5/2.0 |
| JXF504025 | 500 | 400 | 250 | 1.0/1.2/1.2 |
| JXF605025 | 600 | 500 | 250 | 1.2/1.5/1.5 |
| JXF806025 | 800 | 600 | 250 | 1.2/1.5/1.5 |
| JXF1008025 | 1000 | 800 | 250 | 1.5/2.0/2.0 |
| JXF1008030 | 1000 | 800 | 300 | 1.5/2.0/2.0 |
| JXF12010030 | 1200 | 1000 | 300 | 1.5/2.0/2.0 |
Industrial 3 phase power distribution box
|
