Categories | LiFePO4 Battery Pack |
---|---|
Brand Name: | CLF |
Model Number: | CLF-R0262 |
Certification: | CE,MSDS |
Place of Origin: | Hunan,China |
MOQ: | 1 unit |
Price: | Negotiable |
Payment Terms: | T/T |
Supply Ability: | 1000 units per month |
Delivery Time: | 7-15 working days |
Packaging Details: | Wooden case and Carton case |
Nominal capacity: | 400Ah |
Nominal Voltage: | 12.8V |
Cycle life: | 6000 times |
Size: | 480*240*235mm Customized |
Weight: | 44kg |
Charging Current: | 150A |
Discharge current: | 150A |
BMS Function: | Overcharge, overdischarge, overcurrent, short circuit, etc |
Case material: | Metal case or stainless steel case(Customized) |
Warranty: | 5Years |
Optional: | Bluetooth |
Application: | RV,air conditioners,water heaters,digital equipment etc |
Company Info. |
Hunan Chalong Fly Technology Co., Ltd. |
Verified Supplier |
View Contact Details |
Product List |
CLF Lithium Iron Phosphate Rechargeable Battery LiFePO4 Battery Pack 100Ah 200Ah 300Ah 400Ah 12V 24V For RV Camper Boat
Deep Cycle 100Ah 200Ah 300Ah 400Ah 12V 24V Lithium Iron Phosphate Rechargeable Battery
Specification
Battery model | CLF12400 | ||
Voltage | 12.8V | ||
Battery Type | LiFePO4 | ||
Connection | 4S4P | ||
Capacity | 400AH | ||
Charging voltage | 14.6V | ||
Discharge cutoff voltage | 10V | ||
Maximum charging current | 150A | ||
Maximum discharge current | 150A | ||
Charging temperature | 0~45℃ | ||
Discharge temperature | -10~45℃ | ||
storage temperature | -20~60℃ | ||
BMS protection strategy | Eight major protections | ||
Weight(kg) | 44kg | ||
DimensionsL*W*H(mm) | 480*240*235mm | ||
Display method | Battery display/external screen display | ||
Fire and explosion proof | Built-in fire extinguishing device | ||
heating | |||
cooling method | natural cooling | ||
battery casing | metal shell | ||
communication method | RS485/CAN/GSM(option) |
Advantages of LifePO4 compared with lead-acid batteries:
-Various kinds of green, non-toxic and non-polluting raw materials.
-Long lifespan (2000-8500 cycles, lead-acid is ~400).
-Lightweight-save 60% weight
-Charging speed increased by 6 times
-Reduce the total life cycle cost.
-No heavy metals or acids; environmentally friendly
-Maintenance-free.
-Internal BMS; higher reliability.
-No memory effect.
-Less affected by high temperature.
-Can be installed in any direction
FAQs:
Q: Are you manufacturer?
A: We are manufacturer, and we sincerely welcome you to visit our factory!
Q. Can I print my LOGO on it?
A: YES, LOGO/sticker/OEM/ODM welcomed
Q: Do you accept OEM/ODM?
A: Yes,it is available.We have OEM group to design battery case.
Thanks to send us your requirements to custom the batteries.
Q: What kind of certificates do you have?
A: We can provide CE,ROHS,FCC,IEC62133,MSDS,UN38.3, UL, etc.
Contact us for more informations!
![]() |
