24-key silicone CAN bus communication panel with IP67 rating and customizable options

Categories CANbus Customizable Keypad
Brand Name: GDJD
Model Number: VA-KB-D024
Certification: CE
Place of Origin: China
MOQ: 20PCS
Price: RMB 500-600 PCS
Payment Terms: L/C
Supply Ability: 2000PCS/Per Month
Delivery Time: 30 work days
Packaging Details: Carton Box
Protection Rating: IP67
Interface: CANbus
Key Color: Black
Operating Temperature: -40°C to 85°C
Number Of Keys: 24
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

24-key silicone CAN bus communication panel with IP67 rating and customizable options

24-key silicone CAN bus communication panel with IP67 rating and customizable options


Key icon informationCan be more customized on demand
Working voltage9-36V
Working temperature-40℃~+85℃
Power consumption<5W
Communication method1 channel CAN2.0B (supporting standard and extended frames), compatible with CAN-Open and J1939
Test Times>1000K
Indicator lightsEach button has 3 indicator lights, red, yellow, and green
Backlight colorWhite
silicone panelsilicone panel, engineering plastic back cover.
IP RatingIP67
Random vibrationIEC60068-2-64
Humidity cycleEN60068-2-30: 2006
Surge impact

ISO7037-2: 2004 EN61000-4-5 ±2k



Typical application areas include:
★ Construction machinery, such as excavators, cranes, and rotary drilling rigs, etc.
★ Sanitation machinery, such as sweeper trucks, garbage compression trucks, food waste trucks, and other related sanitation special vehicles
★ Logistics and transportation equipment
★ Aerospace electronic equipment
★ Healthcare equipment
Customization can include:
★ Button patterns, laser-engraved patterns can be customized according to specific functions
★ Panel start-up methods
★ CAN bus parameters, such as data frame formats for receiving and sending frames, baud rate, and ID numbers for bus data, etc.
